| Place of Origin: | China |
|---|---|
| Brand Name: | Ally Hi-Tech |
| Model Number: | Hydrogen UPS |
| Price: | Negotiable |
| Packaging Details: | Seaworthy Package |
| Rated Power: | 5kW | Noise: | ≤60dB |
|---|---|---|---|
| Protection Class: | IP54 | Temperature: | -5～45℃ |
| High Light: | ups unit power supply,uninterrupted power system |
||
Backup Power System 5kW Low Pollution UPS Long Time Safe Operation
The principle of this UPS is hydrogen + fuel cell. The feedstock is methanol and through the methanol-reforming process, high purity hydrogen is generated. Then the fuel cell will make use of hydrogen and generate power to supply stable electricity.
The biggest advantage of Ally's uninterruptible power system is long time operation. As long as the feedstock is enough, the UPS can work continuously.
Performance
Classic Case
Telecommunication base stations and a refuge in the mountainous area of Taiwan: 20Nm3/h methanol hydrogen generator and 5Kw×4 matched fuel cells. Methanol-water storage: 2000L, it can reserve for 74hr continuous use time with output of 25Kw, and supply emergency power for 4 mobile communication base stations and one refuge.
3kW continuous power supply system configuration, L×H×W(M3):0.8×0.8×1.7(can guarantee 24 hours continuous power supply, if longer power supply is required, it needs external fuel tank)
Reference
