| Place of Origin: | China |
|---|---|
| Brand Name: | Ally Hi-Tech |
| Price: | Negotiable |
| Packaging Details: | Seaworthy Package |
| Delivery Time: | 10~15 months |
| Product Concentration: | 35%, 50% | Hydrogen Consumption: | 240 Nm3/ton-H2O2 (35%) |
|---|---|---|---|
| Air Consumption: | 1,600 Nm3/ton-H2O2(35%) | 2-EAQ Consumption: | 0.76 Kg Nm3/ton-H2O2 |
| High Light: | industrial production of hydrogen peroxide,hydrogen peroxide generator |
||
General
Hydrogen peroxide is a kind of environment-conscious product. Its production adopts anthraquinone palladium catalyst fixed bed hydrogenation process which includes below parts: hydrogenation, oxidation, extraction and purification, post-treatment, makeup, and concentration.
In the presence of the Pd catalyst, the alkyl anthraquinone dissolved in the organic solvent is hydrogenated to produce the alkyl anthrax-hydroquinone, which is oxidized to get the hydrogen peroxide under given reaction conditions eventually.
Meanwhile, the alkyl anthrax-hydroquinone is converted into alkyl anthraquinone and the stream of working solution contained H2O2. The resulting stream of working solution is fed to the extraction column for extraction by using demineralized water as extracting agent in a counter-current flow to produce H2O2, which is purified to form the finished product-H2O2 and it will be delivered to the storage tank.
The solution of alkyl anthraquinone after treatment returns to the hydrogenation section for reuse.
Process Schematic
Features
The technology is mature, process line is simple, short and reasonable, furthermore, energy consumption is low
Automation is high, the operation is safe, simple and reliable
Performance
|
No. |
Item |
Value |
Remark |
|
1 |
Product Concentration |
35%, 50% |
|
|
2 |
Hydrogen Consumption |
240 Nm3/ton-H2O2 (35%) |
|
|
3 |
Air Consumption |
1,600 Nm3/ton-H2O2(35%) |
|
|
4 |
2-EAQ Consumption |
0.76 kg Nm3/ton-H2O2 |
|
|
5 |
Electricity Consumption |
kW/h-ton-H2O2 |
|
|
6 |
Capacity |
5,000 ~ 100,000 MPTA |
|
Application
Hydrogen peroxide is a kind of environment-conscious product, and it is mainly used in three fields, say, bleaching, chemical synthesis, and environmental protection.
Moreover, it is widely used in fields of medical, war industry, chemical synthesis, textile, paper making, environmental protection, food, metallurgy, and agriculture, etc.
