Compact Hydrogen Plant From Methanol , High Purity Hydrogen Generator Plant

Compact Hydrogen Plant From Methanol, High Purity Hydrogen Generator Plant

General

The energy required by the methanol reforming is maintained by off-gas and methanol which are oxidized in presence of catalyt and genrate the heat accordingly.

Features

• Flameless, hot oil furnace could be deployed adjacent reformer;
• Less NOx, lower temperature in the furnace;
• Less hot oil piping, less heat loss, higher system efficiency;
• Recovering off-gas, less methanol consumption.

Process Schmatic

Performance

• Hydrogen Capacity:100～600 Nm3/h
• Hydrogen Purity:99%～99.9995%
• Hydrogen Pressure:～1.0 Mpa(G)

Reference
