Application: | On-site Hydrogen Generation | Performance: | Reliability Greater Than 99.6% |
---|---|---|---|
Footprint: | Modularization | Automation: | Fully Automatic |
Configuration: | Simple | Technology: | Pre-fabricated Skid |
High Light: | hydrogen gas generation plant,steam methane reforming hydrogen production |
Small Hydrogen Gas Generation Plant Associated With PSA 400 Kg/D - 1200 Kg/D
General
To address small-scale to medium-scale on-site hydrogen generation, Ally development the hydrogen generation process based on the methanol reforming associated with the PSA purification system. After decades of development, Ally has been granted tens of patents and formulated the Chinese standard in this field.
Ally has gotten extensive experience through the cooperation with top-ranked multi-national companies who are engaged in the on-site hydrogen supply, such as Air Liquide, Linde, Praxair, etc..
Features
Pre-fabricated skid technology reduces the huge on-site installation workload.
suitable for hydrogen filling station
It is a mature production technology, which can be operated safely and reliably.
The feedstock is easy to get by a small price fluctuation, and transported and stored easily too.
The process flow is short and simple,less land occupation and investment which can be recovered in a short period.
Automation is high and operation is simple and easy.
Both energy consumption and production cost are low.
No environmental pollution.
Process Schematic
Process Description
The mixture of methanol and de-mineralized water, after pressurized, evaporated and superheated to a certain temperature, is fed into a reactor, where the reforming gases including H2, CO2, CO, etc. are formed under the action of the catalyst. The mixed gas is treated through the purification technology of PSA to get high purity hydrogen in one cycle.
Performance
Hydorgne Capacity: 400 kg/d ~ 1,200 kg/d
Hydrogen Purity: 99.99% (v/v)
Temperature : ambient
Product pressure: 0.8~2.5 MPa(G)
