Product Concentration: | 35%, 50% | Hydrogen Consumption: | 240 Nm3/ton-H2O2 (35%) |
---|---|---|---|
Air Consumption: | 1,600 Nm3/ton-H2O2(35%) | 2-EAQ Consumption: | 0.76 Kg Nm3/ton-H2O2 |
High Light: | hydrogen peroxide manufacturing plant,industrial production of hydrogen peroxide |
Economic Hydrogen Peroxide Production Plant 35% 50% Product Concentration
General
Hydrogen peroxide is a kind of environmentally conscious product. Its production adopts anthraquinone palladium catalyst fixed bed hydrogenation process which includes below parts: hydrogenation, oxidation, extraction and purification, post-treatment, makeup, and concentration.
In the presence of the Pd catalyst, the alkyl anthraquinone dissolved in the organic solvent is hydrogenated to produce the alkyl anthrax-hydroquinone, which is oxidized to get the hydrogen peroxide under given reaction conditions eventually. Meanwhile, the alkyl anthrax-hydroquinone is converted into alkyl anthraquinone and the stream of working solution contained H2O2. The resulting stream of working solution is fed to the extraction column for extraction by using demineralized water as extracting agent in a counter-current flow to produce H2O2, which is purified to form the finished product-H2O2 and it will be delivered to the storage tank. The solution of alkyl anthraquinone after treatment returns to the hydrogenation section for reuse.
Process Schematic
Features
Performance
No. | Item | Value | Remark |
1 | Product Concentration | 35%, 50% | |
2 | Hydrogen Consumption | 240 Nm3/ton-H2O2 (35%) | |
3 | Air Consumption | 1,600 Nm3/ton-H2O2(35%) | |
4 | 2-EAQ Consumption | 0.76 kg Nm3/ton-H2O2 | |
5 | Electricity Consumption | kW/h-ton-H2O2 | |
6 | Capacity | 5,000 ~ 100,000 MPTA |
Application
Hydrogen peroxide is a kind of environment-conscious product, and it is mainly used in three fields, say, bleaching, chemical synthesis, and environmental protection. Moreover, it is widely used in fields of medical, war industry, chemicals synthesis, textile, paper making, environmental protection, food, metallurgy and agriculture etc.
