Reliable Hydrogen PSA Unit , Hydrogen Production Unit Decarbonization By PSA

Basic Information
Place of Origin: China
Brand Name: Ally Hi-Tech
Price: Negotiable
Packaging Details: Seaworthy Package
Detail Information
Automation: High Process: Simple Configuration
Performance: High Performance Capacity: 5,000~100,000 Nm3/h
High Light:

hydrogen production unit


hydrogen generation system

Product Description

Reliable Hydrogen PSA Unit , Hydrogen Production Unit Decarbonization By PSA


The features, process principle and process flow of PSA decarburization technology are the same as those of PSA purification of hydrogen.


The distinction is that the feed gas to the PSA is a mix rich in CO2, and the outcome gas can be H2, N2, and CO.




  • Mature and stable generation technology

  • Smooth processes, efficient operation, and quick action for startup & shutdown

  • High level of automation, simple and safe operation and control steady, secure and reliable

  • Can recover less land occupation and investment in a short time

  • Cost-effective operation and production

  • Recover CO2 at >90% high concentration


Process Principle


Decarburization separates carbon dioxide from other gaseous parts by using the properties of the adsorbents, which are selected to adsorb carbon dioxide in the gas blend under pressurized conditions.


In the meantime, the adsorbents release the adsorbed CO2 under decreased pressure to refresh the adsorbents. According to the customers' diverse requirements for the carbon dioxide content of the product, a one-stage or two-stage operation is adopted to ensure the production of the active ingredient and the stability index.


Process Description


CO2 rich feed gas is pretreated and then entered into the PSA system from the bottom of the adsorption tower. Purified gas (H2, N2, CO) is obtained from the top of the tower. From the bottom of the tower we get the desorption gas (main content is CO2) so to recover CO2 or release it into the atmosphere.



  • Capacity: 5,000~100,000 Nm3/h

  • Remaining CO2 : ≤ 0.2%(v/v)

  • Pressure : 0.3~3.6MPa(G)

  • Hydrogen Recovery: ≥98%(v/v)

  • Nitrogen recovery: ≥90%(v/v)

  • CO recovery: ≥92%(v/v)


  • CO2 removal and purification from water gas and semi water gas

  • CO2 removal and purification from shift gas

  • CO2 removal and purification from pyrolysis gas of methanol cracking

  • CO2 removal or concentration from other sources of CO2 –rich gases
