Economical Hydrogen Production Plant , Psa Unit For Hydrogen Production

Basic Information
Place of Origin: China
Brand Name: Ally Hi-Tech
Price: Negotiable
Packaging Details: Seaworthy Package
Detail Information
Feedstock: Hydrogen Rich Gases Process: Robust PSA Technology
Service: Site Supervision Available Condition: New
High Light:

industrial hydrogen generator


hydrogen generator plant

Product Description

Economical Hydrogen Production Plant, PSA Unit For Hydrogen Production



How does a PSA plant works?


Pressure swing adsorption (PSA) is one economical and efficient technology using to recover the hydrogen from the hydrogen-rich gases, such as syngas, waster-gas, various off-gases.


The principle of applying PSA gas purification process is by utilizing the characteristics of adsorbents with selectivity towards different absorbing substances and with variations of absorbing the capacity to the absorbing substance following the change of pressure, absorbing impurities composition in the feedstock under high pressure and desorbing the impurities under low pressure to reactivate the adsorbents. The complete operation process is proceeding under ambient temperature.


PSA working procedures are basically divided into adsorption and regeneration. The regeneration of adsorbents can be divided into 3 sub-procedures as follows:


i. Reduce the pressure of adsorber;

ii. Purge and blow down the adsorbents at low pressure.

iii. Increase the pressure of adsorber to return to the next cycle after the adsorbents are regenerated


To ensure the feedstock filled in continuously and the hydrogen output continuously, generally, there are more than 4 absorbers are staggered, comprising a closed loop to ensure the feedstock filled in continuously and the product output continuously. Commonly, One or two adsorbers are in adsorption. The complete process is mainly realized by program control valves.


Plant features of PSA hydrogen recovery plant


• Design for long service life

• A wide range of the turndown ratio, commonly from 30% to 110%.

• High reliability

• High quality and safety standard

• Fully automatic operation and. remote monitoring

• Pre-fabricated valve skid.

• Switch-back to operation with reduced adsorber.


Additional Features


• On-line maintenance is possible, if required.

• On-line analyzers are available, if required.

• International standards and certificates are applicable, such as ASME/ANSI, TR CU.


Plant Performance


• Feedstock: syngas, water gas, hydrogen-rich gases (such as coke-oven gas, off-gas from Chlor-alkali plant)

• Hydrogen capacity: 5 to 100,000 Nm3/h

• Feed pressure: 7 to 35 barg

• Hydrogen purity: typically 99.99%; higher purity could be tailored.
