| Place of Origin: | China |
|---|---|
| Brand Name: | Ally Hi-Tech |
| Model Number: | SMR |
| Price: | Negotiable |
| Packaging Details: | Seaworthy Package |
| Capacity: | 50~500,000Nm3/h | OPEX: | Low |
|---|---|---|---|
| Operation: | Stable | Automation: | High |
| High Light: | hydrogen manufacturing unit,hydrogen gas plant |
||
Hydrogen Plant by Advanced SMR Technology Small Capacity 50Nm3/h
Ally Hi-Tech is able to provide 50Nm3/h SMR hydrogen plants for our clients. Meanwhile, If you need plants with bigger capacity, 100Nm3/h, 200Nm3/h are good options as well. All the plants with capacities mentioned will be prefabricated in our factory, shipped and installed as compact skids. It is also very suitable for limited land or strict land occupation request.
Principle
The principle of SMR technology is as follows:
After compression and desulfurization, natural gas, the feedstock of this hydrogen production process, reacts with steam in the presence of catalysts. We can use this chemical formula to describe this reaction more clearly.
Step 1: CH4+H2O→3H2+CO -Q
By this reaction, a lot of heat will be released and we use an economizer to collect the heat.
Next, the syngas enters the shifter and the carbon monoxide will be changed into carbon dioxide.
Step 2: CO+H2O→H2+CO2 +Q
In the end, after the purification of the PSA system, high purity product hydrogen will be collected in the tank.
