Methanol Reforming Hydrogen Ups Backup Power Supply 3kW Light Weight

Basic Information
Place of Origin: China
Brand Name: Ally Hi-Tech
Model Number: UPS
Price: Negotiable
Packaging Details: Seaworthy Package
Detail Information
Operation: Long Time Output Power: 3kW
Temperature: -5~45℃ Type: Hydrogen UPS
Material: Methanol
High Light:

ups unit power supply


uninterrupted power system

Product Description


Methanol Reforming Hydrogen 3kW Backup Power System Long Run UPS​


Different from other kinds of UPS, Ally Hi-Tech combined hydrogen production by methanol-reforming and fuel cell system together. The biggest advantage of hydrogen UPS is its long operation time. Because it is hydrogen energy UPS, pollution and carbon emission is very low. Besides, the noise is lower than 60dB.




No. Item Value
1 Rated Voltage 48VDC
2 Rated Power 3kW/5kW
3 Methanol Consumption ~0.5kg/kW
4 Operation Temperature Ambient
5 Stack Design Life min.5000h (Continuous)
6 Noise max.60dB
7 Protection Class IP54
8 Outline Dimension 0.8m x 0.8m x 1.7m





1. High purity hydrogen is obtained through the patented technology, heat and DC output are obtained after passing through fuel cell, hydrogen purity is high, and fuel cell lifetime is long
2. It can be combined with solar energy, wind energy and storage battery to become a comprehensive backup power supply solution
3. It is outdoor case of IP54 class with light system weight and compact structure, which can be installed outdoor and on the roof
4. Quiet operation & Low carbon emission
5. Quick Start-up.






Methanol Reforming Hydrogen Ups Backup Power Supply 3kW Light Weight 0
