Name: | High Performance PSA Nitrogen Generator | Performance: | High Performance |
---|---|---|---|
Automation: | Fully Automatic | Technology: | Modularisation |
Reliability: | High | ||
High Light: | PLC PSA nitrogen gas generator,PSA nitrogen plant Modularisation,High precision PSA n2 generator |
High Performance PSA Nitrogen Generator 5 - 6000 Nm3 /h Nitrogen Capacity
Process Description
A supercharger is used to increase air pressure. Then, a freeze dryer is introduced to remove moisture. Finally, a carbon molecular sieve bed is used to separate nitrogen from oxygen, thus guaranteeing the desired nitrogen product.
The adsorbent is carbon molecular sieve. It is precisely by utilizing the different adsorption rates of oxygen and nitrogen on the surface of the carbon adsorbent to adsorb O2 and desorb N2. Controlled by a programmable controller (PLC), the on-off valve completes each cycle of adsorption and desorption, and then produces nitrogen at the desired purity. The two adsorbers alternate adsorption and desorption to ensure continuous and stable nitrogen generation.
Technical Features
Performance
Nitrogen Capacity | 5 ~ 6,000 Nm3/h |
Nitrogen Purity | 95% ~ 99.999% (v/v) |
Pressure | 0.1~1.0MPa(G) |
Dew Point at Atmospheric | |
Pressure | -40℃~-55℃ |
