| Place of Origin: | China |
|---|---|
| Brand Name: | Ally Hi-Tech |
| Model Number: | UPS |
| Price: | Negotiable |
| Packaging Details: | Seaworthy Package |
| Operation: | Long Time | Output Power: | 3kW |
|---|---|---|---|
| Temperature: | -5～45℃ | Type: | Hydrogen UPS |
| Material: | Methanol | ||
| High Light: | Hydrogen Uninterruptible Power System,3kW UPS Backup Power Supply,3kW ups power supply |
||
Methanol Reforming Hydrogen 3kW Backup Power System Long Run UPS
Different from other types of UPS, Ally High-Tech combines methanol reforming hydrogen production and fuel cell system. The biggest advantage of a hydrogen UPS is the long runtime. Because it is a hydrogen energy UPS, the pollution and carbon emissions are very low. In addition, the noise is lower than 60dB.
Performance
| No. | Item | Value |
| 1 | Rated Voltage | 48VDC |
| 2 | Rated Power | 3kW/5kW |
| 3 | Methanol Consumption | ~0.5kg/kW |
| 4 | Operation Temperature | Ambient |
| 5 | Stack Design Life | min.5000h (Continuous) |
| 6 | Noise | max.60dB |
| 7 | Protection Class | IP54 |
| 8 | Outline Dimension | 0.8m x 0.8m x 1.7m |
